primary_beam
¶
Tests for the functions in WODEN/src/primary_beam.c
. These functions
setup primary beam settings, ready to calculate beam responses on the GPU.
test_fill_primary_beam_settings.c¶
primary_beam::fill_primary_beam_settings
prepares a beam_settings_t
struct to be used by calculate_visibilities::calculate_visibilities
. The
az,za coords have already been calculated by
chunk_sky_model::create_chunked_sky_models
, which is sufficient for some
beam models. The following beam models need further inputs:
GAUSS_BEAM
andMWA_ANALY
: both need the hour angle of all COMPONENTs for all time steps, sofill_primary_beam_settings
makes this calculation
The tests here call fill_primary_beam_settings
for all primary
beam types, and perform the following checks:
GAUSS_BEAM
:
Assert that
beam_settings->beamtype == GAUSS_BEAM
Assert that a number of constants are copied from
woden_settings
intobeam_settings
GAUSS_BEAM
orMWA_ANALY
Assert that:
src->point_components.beam_decs src->point_components.beam_has src->gauss_components.beam_decs src->gauss_components.beam_has src->shape_components.beam_decs src->shape_components.beam_hashave been set to the correct values for all COMPONENTs and time steps.
- All other beams:
Assert that
beam_settings->beamtype
is set correctly
For FLOAT compiled code, the absolute tolerance threshold on values is set to
1e-7, and 1e-15 for DOUBLE compiled code. For values that are 64 bit in both the
FLOAT and DOUBLE versions the values are tested using TEST_ASSERT_EQUAL_DOUBLE
.
